This European-style double beam gantry crane is engineered and fabricated in strict accordance with advanced European FEM industry standards. Its complete assembly comprises twin main beams, end beam sets, lifting trolley units, electric control systems and operator cabins. Differing from conventional MG-type gantry cranes, this model adopts European-standard manufacturing specifications, surface-hardened reducers, integrated three-in-one driving units, as well as PLC and variable frequency combined control technology. The upgraded design greatly enhances overall equipment performance, while cutting the crane’s self-weight by over 15% and lowering wheel pressure by 10% to 20%.
European-style double beam gantry cranes enjoy extensive applicability in industrial material handling. They are widely deployed in steel metallurgy, hydropower engineering, aerospace, shipbuilding, automobile manufacturing, coal mining and petrochemical industries. The equipment supports bidirectional travelling and flexible lifting and lowering of heavy loads. For working sites with explosive, flammable or corrosive hazards, professional technical measures can be equipped to guarantee safe and stable operation.
Featuring lightweight structure and minimized wheel pressure, this crane serves as an optimal lifting device for diverse material handling scenarios. Its compact overall dimension and low wheel load effectively lower the upfront civil construction investment for factories, and help save daily operational costs on lighting, heating and other auxiliary facilities.
The equipment delivers stable performance and outstanding durability to minimize post-installation operating expenses. Adopting high-grade standard components greatly reduces daily maintenance and repair workload. Meanwhile, the optimized structural and control design cuts the machine’s overall energy consumption, realizing cost-saving and efficient operation in the long run.
Weihua Crane delivers fully tailored European-style double beam gantry crane solutions for heavy-load lifting and high-efficiency industrial handling, complying with authoritative European FEM standards.
Core specifications including lifting capacity, working span, lifting height, working duty and hoist type are all adjustable. Customized configurations adapt to varied operation demands at ports, storage yards and industrial sites, ensuring excellent stability and consistent reliable performance.
Optional Configurations
Alternative electric hoist and container spreader devices
Frequency conversion PLC integrated control for steady operation
Anti-sway system to realize high-precision container positioning
Dual operation modes: remote control and cabin control
Customized design for varied outdoor environments and load types
Our professional engineering team guarantees superior equipment performance, operational safety and long-term service stability, providing advanced lifting solutions for modern container transportation and heavy-duty industrial handling work.
Technical Parameters
| Product Name | European Double Beam Gantry Crane |
|---|---|
| Lifting Equipment | Electric Trolley |
| Capacity (T) | ≥5 ton |
| Span (M) | 10.5 - 31.5 meter |
| Lifting Height(M) | 6 - 12 meter |
| Work Duty | M5 |
| Hoist Speed (m/min) | 2 - 20 |
| Crane Speed (m/min) | 3 - 30 |
| Working Temperature (℃) | -20 - 40 |
| Power Source | Three-Phase A.C. 380V 50Hz |
| Operational Method | Ground Control + Remote Control |
