Insulating overhead cranes are widely applied in circumstances where electricity is used to work or lift some goods that carry electricity. Insulating overhead cranes always lift some products or materials like electrolytic aluminum, electrolytic copper, and non-ferrous metallurgy for anti-electric leakage and safe hoisting under high-voltage working conditions.
Why WEIHUA’s Insulating Overhead Crane?
1.Multiple functions and applications: WEIHUA’s insulating overhead crane has a variety of applications in industries and areas like non-ferrous metal electrolytic smelting, the electronics industry, the power industry, and chemical electrolysis.
2.Security: This overhead crane has multiple layers of insulation protection that prevent current from being conducted from the lifted load to the crane. So, it can protect people from electric shock, and can eliminate the life-threatening risk of electric shock injuries and fatalities.
Product Features
1. Insulation treatment at key components
Insulation devices are installed at three or more critical points, including the hook, pulley block, hoisting mechanism, and trolley frame. An epoxy-phenolic laminated glass-cloth insulating bushing is applied between the hook and the pulley block, with a voltage withstand rating of up to 35 kV or above. At the connection between the hoisting mechanism and the trolley frame, an integral insulating base plate and insulating bearing housings are additionally installed.
2. Insulation resistance standard
Under ambient conditions of typically 20 °C–25 °C and relative humidity ≤ 85 %, the insulation resistance at each insulated point shall be no less than 1 MΩ (megohm).
3. Grounding protection
Provides effective grounding to protect personnel on the ground from electric shock.
4. Dual-brake system
The main hoisting mechanism is equipped with dual brakes to ensure safety, reliability, and efficiency.
If you require this insulation overhead crane at your workshops, please do not hesitate. Leave us an inquiry, get more details and a quote. Our sales will reach out to you within 24 hours.
